Description
PREORDER FOR PRODUCTION RUN #3 NOW OPEN. Estimated ship date is late October. NEW option to add on press plate to ship with your order for a bundle price.
Precision CNC-machined 6061 aluminum alignment and welding fixture designed to assist with accurate positioning and alignment of compatible components during fabrication and welding operations.
Features
- CNC-machined 6061 aluminum construction
- Full-length fixture body
- Precision guide rail / blocking bar alignment rail
- 5/16″ front threaded positive-stop system
- 5/8″ rear threaded extraction provision
- Outer diameter 35 mm
- Designed for repeatable component alignment
- Reusable depending on application and handling
- Precision fabrication tool intended for experienced welders and metalworkers
Because parts kits can vary quite a bit from one kit to another, some fixtures may have a slightly different fit depending on the parts being used. For example, receivers we have encountered have measured anywhere from 34.97 mm to 35.18 mm. The fixture is 35.00 and we do our best to accommodate the range we see in the kits we work with.
The jig is designed for a snug fit but not to be too tight that it’s difficult to remove. This may require fitment and clearancing on your end. Due to the differences between individual kits and components, we cannot guarantee the exact same fit on every kit. Some variation in fit should be expected. Our fixtures are made with these differences in mind, and we generally favor allowing for a little more material rather than making the fit too loose.
Important Product Information
This product is sold as a standalone fabrication fixture only.
No firearm, frame, receiver, receiver blank, firearm parts kit, or firearm components are included with this product.
The fixture is intended solely as an alignment and welding aid. It does not determine finished dimensions or replace the user’s responsibility for proper measurement, fabrication, welding, or inspection.
Some applications may require fitment or adjustment depending on the components being used.
Images showing the fixture or demonstration components are provided solely to illustrate the fixture’s physical characteristics and method of use. Demonstration components are not included unless specifically stated in the product listing.
Purchasers are solely responsible for determining and complying with all applicable federal, state, and local laws and regulations. All NFA / GCA laws apply.
Nothing on this page constitutes legal advice or an ATF determination concerning the legal status of any firearm, component, or fabrication process.
SAS Restorations does not provide instructions, guides, templates, or other materials in accordance with federal law.
Returns
Welding fixtures are eligible for return only if no parts have been installed on the fixture and the fixture is returned in its original, unused condition.
Returned fixtures must be free of scratches, damage, modifications, weld marks, or other signs of use. A restocking fee may apply to eligible returns.
Any welding fixture that has had parts installed, been modified or damaged, or otherwise shows scratches, weld marks, or other signs of use may not be eligible for return.
